Smart Heavy Shelf 1208 & 1210

SHS-1208 / SHS-1210

A drop-in shelf that partitions a Smart Heavy Pac into 1/2, 1/3 or 2/3 levels — protect and separate stacked goods without a second carrier. Available for both the 1200 × 800 and 1200 × 1000 footprints; up to 23 per container, each with its own RFID label.

Talk to our experts

Why this carrier

Flexible partitioning

Split the interior into 1/2, 1/3 or 2/3 levels — up to 23 shelves per erected container.

Protects the load

Prevents load and pressure damage and stops goods from blocking between levels.

Fast to install

Drops straight into an erected Smart Heavy Pac for smooth operations.

Tracked via SAM

Each shelf carries its own RFID label; a stack of 23 is cleaned and checked (X/23).

Smart Heavy Shelf 1208

Load-bearing divider for the SHP-1208

Dimensions: 1132 × 732 × 30,5 mm
Weight: 9,65 kg
Payload: 250 kg

Smart Heavy Shelf 1210

Load-bearing divider for the SHP-1210

Dimensions: 1132 × 932 × 30,5 mm
Weight: 10,47 kg
Payload: 250 kg

Volume split in the SHP-1208

The SHS-1208 is the load-bearing intermediate layer inside the foldable large container (FLC) Smart Heavy Pac 1208. Depending on orientation it splits the internal volume into equal, protected levels — keeping stacked goods separated and blocking-free:

1/2 + 1/2

1/3 + 1/3 + 1/3

1/3 + 2/3

2/3 + 1/3

Technical data

External dimensions (L × W × H)	1132 × 732 × 30,5 mm
External dimensions incl. pins (L × W × H)	1132 × 792 × 30,5 mm
Tare weight	9,65 kg
Material	Polypropylene (PP)
Thickness (height)	30,5 mm
Payload (universally distributed load, UDL)	250 kg
Temperature resistance	−30 °C to +40 °C
Water temperature (cleaning)	+2 °C to +65 °C
Tracking	RFID label per shelf

Technical drawings

smart-heavy-shelf technical drawing — 1208 combined (metric)

Delivery of the SHS

Erected SHP: up to 23 shelves

When erected, up to 23 shelves (SHS) fit inside one Smart Heavy Pac. You receive it ready to use — for 1/2, 1/3 or 2/3 levels straight away.

RECALO SHS “inspected & cleaned” label — 23 dividers inside

An “inspected & cleaned” label on the Smart Heavy Pac confirms the shelves inside were checked and cleaned and are ready for use. If the quantity differs, it is noted on the label (X/23).

Return of the SHS

Folded SHP: exactly one shelf

For the return trip, exactly one Smart Heavy Shelf goes onto a folded Smart Heavy Pac — it sits neatly over the folded walls and under the lid, whatever the footprint (1208 or 1210).

One Smart Heavy Shelf resting on a folded Smart Heavy Pac for return transport — The light shelf resting on top is the one Smart Heavy Shelf.

Never place two shelves in a folded carrier: it damages the lid, walls and base and stops the folded containers from stacking correctly.

FAQ

Frequently asked questions

How many fit in one container?

Up to 23 shelves fit in one erected Smart Heavy Pac.

How does it subdivide the container?

The 1200 × 800 (SHS-1208) offers four layouts depending on orientation: 1/3 + 2/3, 1/2 + 1/2, 1/3 + 1/3 + 1/3, or 2/3 + 1/3. The 1200 × 1000 (SHS-1210) divides the container into two equal halves (1/2 + 1/2) only.
